Histone proteins are decorated by a variety of protein posttranslational modifications called histone marks that modulate chromatin structure and function, contributing to the cellular gene expression program. This SnapShot summarizes the reported human, mouse, and rat histone marks, including recently identified lysine acylation marks.

In a SnapShot (short magazine feature) in Cell this week, Huang et al. provide this map of sorts, charting the landscape of histone modifications uncovered to date.
The crystal structure of the histone was resolved by Luger et al. in 1997, showing the octamer was held together by various protein-protein interactions (mainly through contacts between H3 and H3 within the (H3-H4)2 tetramer, and H3-H2B contacts between the tetramer and the H2A-H2B dimers. The histone proteins themselves are strongly basic, such that the entire octamer hydrogen bonds and electrostatically interacts with the [negatively charged] DNA phosphate backbone (as well as through non-polar contacts with the sugar groups). The ‘tails’ of the histone proteins contact neighbouring nucleosomes, and thus fine modifications throughout the structure modulate both the protein-protein and protein-DNA interactions (see Ryan 2011 for the full [thesis-length!] tale including a run-down on the Histone Code Hypothesis).
Histone modifiers, such as histone methyltransferases (often simply ‘methylases’) can act locally, globally, or in restricted domains (as for the H3K27me3 modification, i.e. trimethylathion of lysine 27 on histone 3). Recruitment to chromatin induced by protein’s DNA binding domains, other proteins complex members, TFs, RNA Pol and histone mod’s.
Interestingly, this leads to a system of feedback: modifications themselves recruit modifier enzymes to add further modifications.

Just 7 years ago the landscape was looking a whole lot simpler (as pictured by Bhaumik et al.)
The effects of these marks are usually separated (Ruthenburg et al. 2007, Campos & Reinberg 2009) into the
intrinsic single nucleosome changes, e.g. histone variant specific modifications like H2AX),
extrinsic chromatin organisation, i.e. nucleosome/nucleosome interactions; chromatin packaging, electrostatic charge effects such as H4 acetylation
effector-mediated in recruiting other proteins to chromatin, e.g. bromodomains binding acetylated sites, chromo-like royal domains (chromo, tudor, MBT “Malignant Brain Tumour domain” ) and PHD binding methylated sites, and 14-3-3 proteins binding phosphorylated sites; or preventing binding).
If this appears confusing, last month bioinformatician Ewan Birney wrote up a “cheat’s guide to histone modifications”

There are different types of histone protein. And just to be extra confusing, the same type of histone protein is sometimes made by more than one gene. (A lot of histone protein needs to be made during each cell cycle.)
Histone proteins are mainly compact, globular structures, but each one has a floppy peptide region at the start of the protein, which is described as the histone “tail” (somewhat confusingly in my view, as it’s at the start of the protein! Isn’t it more like a “trunk”?).


There is a raging debate about whether histone modifications can be considered to drive chromatin behaviour, or whether chromatin behaviour is simply a consequence of things which are happening nearby on the chromatin (in particular, transcription factor binding) (I am mainly a “consequence” person here). Either way, these modifications are extremely informative about what is going on in any given cell type.

Kouzarides, 2007, is another nice introductory paper for anyone seeking an introduction, but as Ewan’s post and the prior example emphasise 7 years has been a long time in the world of epigenetics research.

There was an interesting paper out earlier in the year under PLOS Genetics, in which the authors sought to “Uncouple Transcription from Covalent Histone Modification”. To summarise,

It is widely accepted that transcriptional regulation of eukaryotic genes is intimately coupled to covalent modifications of the underlying chromatin template, and in certain cases the functional consequences of these modifications have been characterized. Here we present evidence that gene activation in the silent heterochromatin of the yeast Saccharomyces cerevisiae can occur in the context of little, if any, covalent histone modification… Our results indicate that large increases in transcription can be observed in the virtual absence of histone modifications often thought necessary for gene activation.

The experiment that led them to such a conclusion involved an inducible heat shock gene (which would strongly stimulate transcription of genes involved in the heat shock response) under regulation by SIR. Finding this inducible system worked to produce >200-fold transcriptional induction even with neglible levels of histone modifications (H3K4me3, H3K36me3 and H3K79me2) that had been associated with transcription initiation and elongation.
A paper uploaded to BioRxiv 2 days ago describes a computational method to infer the interactions between chromatin modifiers and histone modifications (the feedback mechanism I referred to above), as a “high-confidence backbone of the chromatin-signaling network”.

The interactions between chromatin modifiers and histone modifications are often unknown, are based on the analysis of few genes, or are studied in vitro… Many recovered interactions have literature support; others provide hypotheses about yet unknown interactions. We experimentally verified two of these predicted interactions, leading to a link between H4K20me1 and members of the Polycomb Repressive Complexes 1 and 2.

Computationally, the technique revolves around use of sparse partial correlation networks (algorithms finding conditional probabilities in gene sequencing data, indicating causal influence) over previous methods of Bayesian Network inference and maximum entropy framework [the schematic overview for which is shown below].

Redundant information
Addressing what Birney described as the “raging debate” on histone modification (HM) causality ‒ whether they drive chromatin and chromatin modifier (CM) behaviour or not ‒ the authors write:

This approach accounts for interactions induced by correlations between HMs. Consequently, we prune the so-derived candidate chromatin-signaling network by computing sparse partial correlation networks, which is aimed to identify direct interactions between HMs and CMs accounting for correlations between CMs and HMs.

They describe the HMs and CMs as holding “redundant information” (both should contain information on gene expression, so for a particular gene they should be saying the same thing). Indeed, ~75% of gene expression variance is capable of attribution to HM and CM levels, “good predictive performance”.

If HMs and CMs reflect the same chromatin-signaling network, both should contain redundant information about gene expression such that combining them should yield only a marginal increase in the predictive power. Indeed, using both, CMs and HMs, improves the explained variance in gene expression only by 3% (4%) compared to using only HMs (CMs) at the expense of a higher model complexity (Figure 1C). Thus, these findings support that CMs and HMs jointly constitute a chromatin-signaling network involved in transcription and its regulation.


Their next step in the analysis showed CM levels accurately predict HM levels and vice versa, the accuracy of the prediction being limited by accuracy in expression and biochemical activity measurements. Having found colocalisation of HMs and CMs, they sought to determine likely CM-HM interacting pairs by first simply selecting the CMs most predictive of HMs and then applying sparse partial correlation networks. Exactly why they did so is a little abstract, but central to the work:

There are groups of HMs and CMs that exhibit very high pairwise correlation, suggesting that they are functionally related. However, within these groups no internal structure is visible, rendering an identification of interactions between the group members difficult. As CMs and HMs constitute a chromatin-signaling network, this high correlation is expected due to direct interactions between its components. However, high correlations could also be induced by other factors connecting the respective CM and HM. In general, the identity of these additional factors is not known, but we can account for those factors that are present in the dataset. Thus, we want to recover interactions between CMs and HMs that cannot be “explained away” by other variables in the dataset.
We recovered these interactions by applying a two-step procedure. First, we used a regularized regression technique called “Elastic Net”, where the CMs are used to predict HMs, to select only CMs that are informative for the prediction of a HM.

For a group of say 3 proteins [CMs] associated with a histone modification (e.g. H3K27me3), the Elastic Net method would try and dissect the contributions of each protein - how much more information one provides on the H3K27me3 HM in addition to the info provided by the other 2 chromatin modifiers.

Moreover, in case of groups of strongly correlated CMs the members of these groups tend to remain all in the model or are removed together. This approach accounts for possible interactions induced by correlations within the CMs but does not take into account correlations between the HMs. This indicates that highly correlated HMs might be predicted by similar sets of CMs, while only certain CMs actually interact with specific HMs.
Second, to remedy this situation we used a technique called “Sparse partial correlation networks” (SPCN), where the pairwise rank correlation between a CM and a HM is conditioned on all other variables in the data set. This method takes into account the correlation structure of both, CMs and HMs, and is conservative in proposing interactions. As a consequence, in groups of strongly correlated CMs and/or HMs, interactions may be explained away by individual members of the group. Thus, in the SPCN framework an identified interaction is likely to represent a direct interaction in the sense that it cannot be explained by other variables in the dataset. However, the failure to recover an interaction does not imply the absence of a biologically meaningful interaction. Within the SPCN framework some interactions between CMs and HMs arise from logical dependencies induced by sharing a common target.
Thus, to recover interactions, we establish first the necessary condition that a CM is consistently highly predictive for an HM level by the Elastic Net approach and in a second step we prune those interactions that may be induced by correlations between the HMs using the SPCN approach. Thus, we focus only on interactions that are recovered by both methods. These interactions may originate from a direct function of the CM in setting, erasing or binding the HM but also from indirect interactions via unobserved CMs.

The important thing to take away from this is that this Elastic Net and SPCN combination is very conservative in its predictions of interactions, i.e. the false positives are minimised at the expense of potential false negatives: valorising specificity over sensitivity.
Sure enough, predicted interactions were backed up in the literature, and a couple of novel ones — H4K20me with CBX2 and EZH2 (components of Polycomb Repressor Complex 1 and 2 respectively) — were verified by the authors themselves upon immunoprecipitation. Interestingly, the finding “may form a mechanistic basis for the maintenance of Polycomb repression through the cell cycle”

The progression of cells through the cell cycle constitutes two challenges for the maintenance of Polycomb-mediated repression: (i) During DNA replication old and newly synthesized nucleosomes are randomly distributed to the daughter strands. This leads to an effective dilution of H3K27me3- bearing nucleosomes by half. (ii) During mitosis HMs, chromatin composition and structure change dramatically, rendering the proper transmission of H3K27me3 difficult.
H4K20me1 is tightly regulated during the cell cycle. It starts accumulating during S-phase and attains high levels during mitosis (37). Given this pattern, H4K20me1 may play an important role in maintaining PRCs at their target sites throughout the replicative and mitotic challenges by recruiting PRCs 1 and 2 to regions with old H3K27me3- and new H4K20me1-bearing nucleosomes.

Compared to the classical kinds of genetic disease (point mutations in a gene leading to a gain or loss of function) histone modification effects clearly present a great deal of complexity.
A little light was shed on the enigmatic complexes last year, when a group of Chinese scientists published cryo-electron microscopy images of the chromatin fibre. The structure produced by Song et al. showed

a histone H1-dependent left-handed twist of repeating tetranucleosomal structural units, within which the four nucleosomes zigzag back and forth with a straight linker DNA.

The veracity of the 30nm fibre in vivo has been challenged; a long-standing debate unresolved by these results. However, even in this garish false colour, they really are stunning.

The chromatin fibre was from the frog Xenopus laevis commonly used in biomedical research, and notably it lacked PTMs of the kind I’ve been discussing above. The paper notes:

Histone modifications and histone variants may also play important roles in the regulation of higher-order chromatin structure via modulating the internucleosomal surface interactions between tetranucleosomal units.

In the same issue in which they were published, Andrew Travers of the MRC-LMB in Cambridge, UK, described how the structures

[resolve] the fundamental issue as to whether the fiber is built from one nucleosome stack — a solenoid — or from two. However, importantly, the new structure differs in one largely unanticipated aspect from most previous models. Instead of the monotonous helix previously imposed by the limitations of the available information, the 30-nm fiber is formed by the tight helical packing of a tetranucleosomal unit. Within this unit, first observed by the crysallization of a tetranucleosome lacking linker histone, the two opposing nucleosome dimers are fully stacked on each other with only a small angular separation.
Between the units, the angular separation is larger and each unit is staggered relative to its nieghbor. The structure agrees well with all other direct measurements but does not exclude the possibility that a nucleosome array may still have the potential to fold into other helical forms.



…modelling of the fiber showed that retention of the tetranucleosome unit necessitated the alternating angular separation of nucleosomes observed by Song et al. However, in a second “idealized” model, some stacking interactions were broken to allow the formation of a more regular structure.
The presence of alternating stacking modes between spatially adjacent nucleosomes implies alternating internucleosomal contacts. In the tetranucleosomal dimer stacks, a major contact is between the exposed surfaces of two H2A-H2B core histone dimers. This interaction is absent in the inter-tetranucleosome contacts, where instead there are contacts between the amino-terminal tail of H4, primarily involving residue Arg-23 [ed: the most basic amino acid] and the acidic patches on the faces of the opposed nucleosomes.
…In the assembled fibers, the bulk of the globular domain of the linker histone is placed asymmetrically with respect to the inward-facing nucleosome dyad so that the principal contacts are at the dyad itself and with each of the entering linker DNA duplexes… The linker histone thus confers polarity on the symmetric core nucleosome in such a way that in the fiber, successive nucleosomes in a stack have opposite polarities, thereby stabilizing coherent stacking in the tetranucleosome unit and helical curvature between these units.
…Although the formation of continuous stacks by nucleosome core particles is well established, their biological relevance has been unclear.

Side note: The paper cited here [published in 2011] contains some pretty poor quality sketches from the early Luger structures (that is, all the way back in 1997), which really underscores the value of Song and colleagues’ work. It does however also contain a type of diagram I’ve never seen for DNA before — a schematic phase diagram of native nucleosome core particles.


Do we expect similar organizations of nucleosome core particles  in the living cell?
In chromosomes, NCPs are connected together by the continuous DNA link. Other components are also present, namely the fifth histone protein H1 and other proteins involved in the functional activity of the genetic material. The living system is therefore of a much higher complexity, with local variations in the concentrations of the multiples components of chromatin. These local heterogeneities offer the possibilities to monitor local changes of short-range interactions between NCPs, via histone tails interactions (the current hypothesis predicts that distinct covalent modifications of the histone tails, such as acetylation, methylation, etc., would determine a code (Jenuwein & Allis 2001). Interestingly, phase transitions can be triggered experimentally using living cells. The whole nucleus already engaged in a process of cell division can be swollen to several times its initial size by changing the ionic conditions, further condensed again by returning to initial ionic conditions to finally complete its cell division process.

Such experiments demonstrate the reversibility of chromatin structural changes upon variations of ionic conditions. Similar reversible phase transitions of unique chromosomes were also obtained experimentally by changing ionic conditions and using micromanipulation techniques (Poirier et al. 2002).
Unfortunately, structural data to understand how chromatin reorganizes during these processes are missing. The ordered phases formed by isolated NCPs in solution can be considered as possible models for the organization of chromatin in vivo. They provide a library of structures that may possibly exist in situ, since they were found under biologically relevant salt and NCP concentration ranges. Telomeric chromatin (a chromatin located at the extremity of chromosomes and playing a crucial role in the control of the lifetime of a given cell; Blackburn 2005) was proposed to be organized in a columnar phase for biochemical reasons, such as the lack of nucleosome positioning and a specific spacing along the DNA (Fajkus & Trifonov 2001). Lamellar structures with a periodicity of about 50 nm were also described in the fish Scyliorhinus sperm cell at a given step of the spermiogenesis process (Gusse & Chevaillier 1978). This organization may remind us of the lamello-columnar phase of NCPs. These and other examples lead us to suspect the possible regular organization of nucleosomes in special types of chromatin, but the structures remain to be analysed carefully, using new available developments of ultrastructural methodology.
More generally, in the classical eukaryotic chromatin, we do not expect the organization of NCPs to extend over long distances, but to be most probably restricted to micro-domains. In the context of the living cell, not only physico-chemical processes but also the activity of numerous enzymes and cofactors would help chromatin to organize in a sophisticated way, following an unknown path in the extremely complex phase diagram of chromatin. We guess that this complexity may offer extremely high possibilities of adaptation of chromatin organization to multiple local constraints.

▚  Huang et al. (2014) Snapshot: Histone Modifications. Cell, 159(2), 458-458.e1
▞  Draker Ryan’s PhD thesis — A Characterization of the Role of Post-translational Modification in Transcriptional Regulation by the Histone Variant H2A.Z.
▚  Ewan Birney’s Cheat’s guide to histone modifications
▞  Perner et al. (2014) Inference of interactions between chromatin modifiers and histone modifications: from ChIP-Seq data to chromatin-signaling. bioRxiv, doi: 10.1101/010132
▚  Zhang et al. (2014) Uncoupling Transcription from Covalent Histone Modification. PLOS Genetics, 10(4): e1004202
▞  Song et al. (2014) Cryo-EM Study of the Chromatin Fiber Reveals a Double Helix Twisted by Tetranucleosomal Units. Science, 344, 376
▚  Andrew Travers (2014) The 30-nm Fiber Redux. Science, 344, 370
▞  Livolant et al. (2006) Are liquid crystalline properties of nucleosomes involved in chromosome structure and dynamics? Phil. Trans. R. Soc. A, 364, 2615-2633

Histone proteins are decorated by a variety of protein posttranslational modifications called histone marks that modulate chromatin structure and function, contributing to the cellular gene expression program. This SnapShot summarizes the reported human, mouse, and rat histone marks, including recently identified lysine acylation marks.

In a SnapShot (short magazine feature) in Cell this week, Huang et al. provide this map of sorts, charting the landscape of histone modifications uncovered to date.

The crystal structure of the histone was resolved by Luger et al. in 1997, showing the octamer was held together by various protein-protein interactions (mainly through contacts between H3 and H3 within the (H3-H4)2 tetramer, and H3-H2B contacts between the tetramer and the H2A-H2B dimers. The histone proteins themselves are strongly basic, such that the entire octamer hydrogen bonds and electrostatically interacts with the [negatively charged] DNA phosphate backbone (as well as through non-polar contacts with the sugar groups). The ‘tails’ of the histone proteins contact neighbouring nucleosomes, and thus fine modifications throughout the structure modulate both the protein-protein and protein-DNA interactions (see Ryan 2011 for the full [thesis-length!] tale including a run-down on the Histone Code Hypothesis).

Histone modifiers, such as histone methyltransferases (often simply ‘methylases’) can act locally, globally, or in restricted domains (as for the H3K27me3 modification, i.e. trimethylathion of lysine 27 on histone 3). Recruitment to chromatin induced by protein’s DNA binding domains, other proteins complex members, TFs, RNA Pol and histone mod’s.

Interestingly, this leads to a system of feedback: modifications themselves recruit modifier enzymes to add further modifications.

Just 7 years ago the landscape was looking a whole lot simpler (as pictured by Bhaumik et al.)

The effects of these marks are usually separated (Ruthenburg et al. 2007, Campos & Reinberg 2009) into the

  • intrinsic single nucleosome changes, e.g. histone variant specific modifications like H2AX),
  • extrinsic chromatin organisation, i.e. nucleosome/nucleosome interactions; chromatin packaging, electrostatic charge effects such as H4 acetylation
  • effector-mediated in recruiting other proteins to chromatin, e.g. bromodomains binding acetylated sites, chromo-like royal domains (chromo, tudor, MBT “Malignant Brain Tumour domain” ) and PHD binding methylated sites, and 14-3-3 proteins binding phosphorylated sites; or preventing binding).

If this appears confusing, last month bioinformatician Ewan Birney wrote up a “cheat’s guide to histone modifications

There are different types of histone protein. And just to be extra confusing, the same type of histone protein is sometimes made by more than one gene. (A lot of histone protein needs to be made during each cell cycle.)

Histone proteins are mainly compact, globular structures, but each one has a floppy peptide region at the start of the protein, which is described as the histone “tail” (somewhat confusingly in my view, as it’s at the start of the protein! Isn’t it more like a “trunk”?).

There is a raging debate about whether histone modifications can be considered to drive chromatin behaviour, or whether chromatin behaviour is simply a consequence of things which are happening nearby on the chromatin (in particular, transcription factor binding) (I am mainly a “consequence” person here). Either way, these modifications are extremely informative about what is going on in any given cell type.

Kouzarides, 2007, is another nice introductory paper for anyone seeking an introduction, but as Ewan’s post and the prior example emphasise 7 years has been a long time in the world of epigenetics research.

There was an interesting paper out earlier in the year under PLOS Genetics, in which the authors sought to “Uncouple Transcription from Covalent Histone Modification”. To summarise,

It is widely accepted that transcriptional regulation of eukaryotic genes is intimately coupled to covalent modifications of the underlying chromatin template, and in certain cases the functional consequences of these modifications have been characterized. Here we present evidence that gene activation in the silent heterochromatin of the yeast Saccharomyces cerevisiae can occur in the context of little, if any, covalent histone modification… Our results indicate that large increases in transcription can be observed in the virtual absence of histone modifications often thought necessary for gene activation.

The experiment that led them to such a conclusion involved an inducible heat shock gene (which would strongly stimulate transcription of genes involved in the heat shock response) under regulation by SIR. Finding this inducible system worked to produce >200-fold transcriptional induction even with neglible levels of histone modifications (H3K4me3, H3K36me3 and H3K79me2) that had been associated with transcription initiation and elongation.

A paper uploaded to BioRxiv 2 days ago describes a computational method to infer the interactions between chromatin modifiers and histone modifications (the feedback mechanism I referred to above), as a “high-confidence backbone of the chromatin-signaling network”.

The interactions between chromatin modifiers and histone modifications are often unknown, are based on the analysis of few genes, or are studied in vitro… Many recovered interactions have literature support; others provide hypotheses about yet unknown interactions. We experimentally verified two of these predicted interactions, leading to a link between H4K20me1 and members of the Polycomb Repressive Complexes 1 and 2.

Computationally, the technique revolves around use of sparse partial correlation networks (algorithms finding conditional probabilities in gene sequencing data, indicating causal influence) over previous methods of Bayesian Network inference and maximum entropy framework [the schematic overview for which is shown below].

Redundant information

Addressing what Birney described as the “raging debate” on histone modification (HM) causality ‒ whether they drive chromatin and chromatin modifier (CM) behaviour or not ‒ the authors write:

This approach accounts for interactions induced by correlations between HMs. Consequently, we prune the so-derived candidate chromatin-signaling network by computing sparse partial correlation networks, which is aimed to identify direct interactions between HMs and CMs accounting for correlations between CMs and HMs.

They describe the HMs and CMs as holding “redundant information” (both should contain information on gene expression, so for a particular gene they should be saying the same thing). Indeed, ~75% of gene expression variance is capable of attribution to HM and CM levels, “good predictive performance”.

If HMs and CMs reflect the same chromatin-signaling network, both should contain redundant information about gene expression such that combining them should yield only a marginal increase in the predictive power. Indeed, using both, CMs and HMs, improves the explained variance in gene expression only by 3% (4%) compared to using only HMs (CMs) at the expense of a higher model complexity (Figure 1C). Thus, these findings support that CMs and HMs jointly constitute a chromatin-signaling network involved in transcription and its regulation.

Their next step in the analysis showed CM levels accurately predict HM levels and vice versa, the accuracy of the prediction being limited by accuracy in expression and biochemical activity measurements. Having found colocalisation of HMs and CMs, they sought to determine likely CM-HM interacting pairs by first simply selecting the CMs most predictive of HMs and then applying sparse partial correlation networks. Exactly why they did so is a little abstract, but central to the work:

There are groups of HMs and CMs that exhibit very high pairwise correlation, suggesting that they are functionally related. However, within these groups no internal structure is visible, rendering an identification of interactions between the group members difficult. As CMs and HMs constitute a chromatin-signaling network, this high correlation is expected due to direct interactions between its components. However, high correlations could also be induced by other factors connecting the respective CM and HM. In general, the identity of these additional factors is not known, but we can account for those factors that are present in the dataset. Thus, we want to recover interactions between CMs and HMs that cannot be “explained away” by other variables in the dataset.

We recovered these interactions by applying a two-step procedure. First, we used a regularized regression technique called “Elastic Net”, where the CMs are used to predict HMs, to select only CMs that are informative for the prediction of a HM.

For a group of say 3 proteins [CMs] associated with a histone modification (e.g. H3K27me3), the Elastic Net method would try and dissect the contributions of each protein - how much more information one provides on the H3K27me3 HM in addition to the info provided by the other 2 chromatin modifiers.

Moreover, in case of groups of strongly correlated CMs the members of these groups tend to remain all in the model or are removed together. This approach accounts for possible interactions induced by correlations within the CMs but does not take into account correlations between the HMs. This indicates that highly correlated HMs might be predicted by similar sets of CMs, while only certain CMs actually interact with specific HMs.

Second, to remedy this situation we used a technique called “Sparse partial correlation networks” (SPCN), where the pairwise rank correlation between a CM and a HM is conditioned on all other variables in the data set. This method takes into account the correlation structure of both, CMs and HMs, and is conservative in proposing interactions. As a consequence, in groups of strongly correlated CMs and/or HMs, interactions may be explained away by individual members of the group. Thus, in the SPCN framework an identified interaction is likely to represent a direct interaction in the sense that it cannot be explained by other variables in the dataset. However, the failure to recover an interaction does not imply the absence of a biologically meaningful interaction. Within the SPCN framework some interactions between CMs and HMs arise from logical dependencies induced by sharing a common target.

Thus, to recover interactions, we establish first the necessary condition that a CM is consistently highly predictive for an HM level by the Elastic Net approach and in a second step we prune those interactions that may be induced by correlations between the HMs using the SPCN approach. Thus, we focus only on interactions that are recovered by both methods. These interactions may originate from a direct function of the CM in setting, erasing or binding the HM but also from indirect interactions via unobserved CMs.

The important thing to take away from this is that this Elastic Net and SPCN combination is very conservative in its predictions of interactions, i.e. the false positives are minimised at the expense of potential false negatives: valorising specificity over sensitivity.

Sure enough, predicted interactions were backed up in the literature, and a couple of novel ones — H4K20me with CBX2 and EZH2 (components of Polycomb Repressor Complex 1 and 2 respectively) — were verified by the authors themselves upon immunoprecipitation. Interestingly, the finding “may form a mechanistic basis for the maintenance of Polycomb repression through the cell cycle

The progression of cells through the cell cycle constitutes two challenges for the maintenance of Polycomb-mediated repression: (i) During DNA replication old and newly synthesized nucleosomes are randomly distributed to the daughter strands. This leads to an effective dilution of H3K27me3- bearing nucleosomes by half. (ii) During mitosis HMs, chromatin composition and structure change dramatically, rendering the proper transmission of H3K27me3 difficult.

H4K20me1 is tightly regulated during the cell cycle. It starts accumulating during S-phase and attains high levels during mitosis (37). Given this pattern, H4K20me1 may play an important role in maintaining PRCs at their target sites throughout the replicative and mitotic challenges by recruiting PRCs 1 and 2 to regions with old H3K27me3- and new H4K20me1-bearing nucleosomes.

Compared to the classical kinds of genetic disease (point mutations in a gene leading to a gain or loss of function) histone modification effects clearly present a great deal of complexity.

A little light was shed on the enigmatic complexes last year, when a group of Chinese scientists published cryo-electron microscopy images of the chromatin fibre. The structure produced by Song et al. showed

a histone H1-dependent left-handed twist of repeating tetranucleosomal structural units, within which the four nucleosomes zigzag back and forth with a straight linker DNA.

The veracity of the 30nm fibre in vivo has been challenged; a long-standing debate unresolved by these results. However, even in this garish false colour, they really are stunning.



The chromatin fibre was from the frog Xenopus laevis commonly used in biomedical research, and notably it lacked PTMs of the kind I’ve been discussing above. The paper notes:

Histone modifications and histone variants may also play important roles in the regulation of higher-order chromatin structure via modulating the internucleosomal surface interactions between tetranucleosomal units.

In the same issue in which they were published, Andrew Travers of the MRC-LMB in Cambridge, UK, described how the structures

[resolve] the fundamental issue as to whether the fiber is built from one nucleosome stack — a solenoid — or from two. However, importantly, the new structure differs in one largely unanticipated aspect from most previous models. Instead of the monotonous helix previously imposed by the limitations of the available information, the 30-nm fiber is formed by the tight helical packing of a tetranucleosomal unit. Within this unit, first observed by the crysallization of a tetranucleosome lacking linker histone, the two opposing nucleosome dimers are fully stacked on each other with only a small angular separation.

Between the units, the angular separation is larger and each unit is staggered relative to its nieghbor. The structure agrees well with all other direct measurements but does not exclude the possibility that a nucleosome array may still have the potential to fold into other helical forms.

…modelling of the fiber showed that retention of the tetranucleosome unit necessitated the alternating angular separation of nucleosomes observed by Song et al. However, in a second “idealized” model, some stacking interactions were broken to allow the formation of a more regular structure.

The presence of alternating stacking modes between spatially adjacent nucleosomes implies alternating internucleosomal contacts. In the tetranucleosomal dimer stacks, a major contact is between the exposed surfaces of two H2A-H2B core histone dimers. This interaction is absent in the inter-tetranucleosome contacts, where instead there are contacts between the amino-terminal tail of H4, primarily involving residue Arg-23 [ed: the most basic amino acid] and the acidic patches on the faces of the opposed nucleosomes.

…In the assembled fibers, the bulk of the globular domain of the linker histone is placed asymmetrically with respect to the inward-facing nucleosome dyad so that the principal contacts are at the dyad itself and with each of the entering linker DNA duplexes… The linker histone thus confers polarity on the symmetric core nucleosome in such a way that in the fiber, successive nucleosomes in a stack have opposite polarities, thereby stabilizing coherent stacking in the tetranucleosome unit and helical curvature between these units.

…Although the formation of continuous stacks by nucleosome core particles is well established, their biological relevance has been unclear.

Side note: The paper cited here [published in 2011] contains some pretty poor quality sketches from the early Luger structures (that is, all the way back in 1997), which really underscores the value of Song and colleagues’ work. It does however also contain a type of diagram I’ve never seen for DNA before — a schematic phase diagram of native nucleosome core particles.

Do we expect similar organizations of nucleosome core particles
in the living cell?

In chromosomes, NCPs are connected together by the continuous DNA link. Other components are also present, namely the fifth histone protein H1 and other proteins involved in the functional activity of the genetic material. The living system is therefore of a much higher complexity, with local variations in the concentrations of the multiples components of chromatin. These local heterogeneities offer the possibilities to monitor local changes of short-range interactions between NCPs, via histone tails interactions (the current hypothesis predicts that distinct covalent modifications of the histone tails, such as acetylation, methylation, etc., would determine a code (Jenuwein & Allis 2001). Interestingly, phase transitions can be triggered experimentally using living cells. The whole nucleus already engaged in a process of cell division can be swollen to several times its initial size by changing the ionic conditions, further condensed again by returning to initial ionic conditions to finally complete its cell division process.


Such experiments demonstrate the reversibility of chromatin structural changes upon variations of ionic conditions. Similar reversible phase transitions of unique chromosomes were also obtained experimentally by changing ionic conditions and using micromanipulation techniques (Poirier et al. 2002).

Unfortunately, structural data to understand how chromatin reorganizes during these processes are missing. The ordered phases formed by isolated NCPs in solution can be considered as possible models for the organization of chromatin in vivo. They provide a library of structures that may possibly exist in situ, since they were found under biologically relevant salt and NCP concentration ranges. Telomeric chromatin (a chromatin located at the extremity of chromosomes and playing a crucial role in the control of the lifetime of a given cell; Blackburn 2005) was proposed to be organized in a columnar phase for biochemical reasons, such as the lack of nucleosome positioning and a specific spacing along the DNA (Fajkus & Trifonov 2001). Lamellar structures with a periodicity of about 50 nm were also described in the fish Scyliorhinus sperm cell at a given step of the spermiogenesis process (Gusse & Chevaillier 1978). This organization may remind us of the lamello-columnar phase of NCPs. These and other examples lead us to suspect the possible regular organization of nucleosomes in special types of chromatin, but the structures remain to be analysed carefully, using new available developments of ultrastructural methodology.

More generally, in the classical eukaryotic chromatin, we do not expect the organization of NCPs to extend over long distances, but to be most probably restricted to micro-domains. In the context of the living cell, not only physico-chemical processes but also the activity of numerous enzymes and cofactors would help chromatin to organize in a sophisticated way, following an unknown path in the extremely complex phase diagram of chromatin. We guess that this complexity may offer extremely high possibilities of adaptation of chromatin organization to multiple local constraints.
